WV408-2000.V1 - EUROTHERME WV408 Signal Conditioner

Product Description
$199.99 USD
Maximum quantity available reached.
3JIndustry


Item Description 100% Authentic
Part # WV408-2000.V1

Description: ULTRA SLIMPAK® II   WV408
DC Powered DC Voltage/Current Input
Isolating Signal Conditioner


Manufacturer: EUROTHERME

System Name: WV408
System SubType: Signal Conditioner

Additional Information: WV408-2000.V1 - Signal Conditioner, ULTRA SLIMPAK® II, WV408 Series, Current, Voltage Input and Output

The WV408-2000.V1 is an Isolating Signal Conditioner with an isolated DC voltage or current output. The Ultra SlimPak II is an exciting new line of isolating signal conditioners from Action Instruments with greater accuracy and better stability than virtually any other signal conditioners on the market today. The Ultra SlimPak II features Smart Power, which eliminates wasted power for low loop resistance loads in the current output mode. The WV408 has both voltage and current input ranges. Four voltage input ranges (±150mV, ±1.5V, ±15V and ±150V) are DIP switch selectable. Each of these ranges has at least 95% zero and span adjustment, which, for example, would allow you to set a 0 to 20mV user range on the ±150mV full scale range. Two current input ranges (±2.5mA and ±25mA) are also DIP switch selectable. "Sigma-Delta" conversion produces an effective resolution of 15 bits. Both voltage and current have input accuracies of 0.015% of full scale.

WV408-2000.V1 - EUROTHERME - Datasheet PDF


Internal Location  -   413  -   160222122730 - JJF

Buy & Sell  PLC Components Allen Bradley, Moeller, Siemens, Omron, Automation Products of All Brand

Real-time pricing and availability, fast shipping on thousands of new and used

Allen Bradley, Moeller, Siemens, Omron, Eaton, Idec, Automation products of all Brand.

  Shipping Information
Shipping Worldwide - Same Day Shipping. UPS - FEDEX - Standard Post - We can use your own shipping service.

  Conditions
All of our products are item that has been used previously or open box. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used.

Sku:
Vendor: EUROTHERME
